Interface
8” Touch Screen Colored Display with User Friendly Software
Sample types
Serum, Plasma, Urine, CSF, Whole Blood and Body fluids
Assay modes
Absorbance, End point, Fixed Time, Kinetic & Multi point
Calibration
Factor, Single Point, Multi Point (Upto 6 Calibration Point and Upto 3 replicates per point)
Calibration Curve
Spline, Point to Point, Linear Regression, Quadratic Regression, Polygonal
Flowcell Volume
18µL
Cuvette Options
Flowcell, Macro Cuvette & Coagulation Cuvettes with Holder
Aspiration Volume
200 – 1000 µL
Light Source
Halogen Lamp
Photometer
Photometer wavelength range from 340-700 nm with minimum 6 wavelengths
Measuring Range
-0.1000 – 3.0000 Abs
Storage
5,000 Patient Results
Quality Control
3 Level for each Parameters, Levey-Jennings Chart, Westgard Rules
Thermostat Range
25° – 37° C
Inbuilt Incubator
8 Position for Chemistry & 5 Positions for Coagulation tests
Printer
Inbuilt Thermal Printer
Ambient Temperature
10 – 35° C
Max. Relative Humidity
< 85 %
Connectivity
2 USB Port
Power Supply
30W, 15 Volt, 100V – 240 V
Certification
CE marked
